Model

10

Operating Weight

880kg

Digging bucket capacity

0.025cbm

Digging bucket width

400mm

Engine

KOOP(KD192)

Rated power

7.6kw

Displacement

6.8ml/r

Bore stroke

single cylinder, fan cool

Main pump

JINXING

Pump flow

16L/min

Hydraulic oil tank capacity

16.5L

Engine oil tank capacity

2.8(1.3)L

Diesel tank capacity

7 L

Working pressure

16Mpa

Valve

BEIFANG

Swing motor

KEERSEN

Traveling motor

USA EATON

Hydraulic oil tank

16.5L

Diesel oil tank

7L

Arm digging force

5.0Kn

Bucket digging force

9.5Kn

Electric pressure

12V

Electrick power

5W

MAIN DEMENSIONS

Overall dimension( LxWxH)

2770x896x1490 mm

Wheelbase

910 mm

Total length of track on land

1230mm

Platform ground clearance

380 mm

Platform back turning radius

784 mm

Chassis width

896 mm

Track width

180 mm

Chassis ground clearance

132 mm

Track height

320 mm

OPERATING RANGE

Max. Digging depth

1650 mm

Max. Vertical digging depth

1375 mm

Max. Digging height

2610 mm

Max. Dumping height

1850 mm

Max. Digging radius on ground

2850 mm

Min. Rotation radius

1330 mm

Max. Upgrade height of bulldozer blade

345 mm

Max. Digging depth of bulldozer blade

255 mm
