DieselEngineSelf-PoweredWoodChipper
Home-->Products-->ICECREDIT MACHINERY-->Wood Chipper-->DieselEngineSelf-PoweredWoodChipper

Product Description:

SPECIFICATION

MODEL WC-50
MAX DIA. OF FEEDING 200MM
POWER CHANGCHAI 4L68 WITH CERTIFICATE(18HP,SINGLE CYCLINDER)
FLYWHEEL DIAMETER 600MM
FLYWHEEL TURNING SPEED 1025RPM
FEEDING SYSTEM

DOUBLE HYDRAULIC FEEDING, ADJUSTABLE SPEED,STOP-REVERSE-FORWARD FUNCTION

NO.OF CUT BLADE 2
SAWDUST MEASUREMENT <4MM
FEEDING OUTLET ROTATION ANGLE 360 DEGREE
WORKING EFFICIENCY 10-14 CUBIC METER
HYDRAULIC OIL TANK 26L

SPECIFICATION

MODEL WC-40
MAX DIA. OF FEEDING 200MM
POWER CHANGCHAI 490Q WITH CERTIFICATE(18HP,4 CYCLINDERS)
FLYWHEEL DIAMETER 600MM
FLYWHEEL TURNING SPEED 1025RPM
FEEDING SYSTEM

DOUBLE HYDRAULIC FEEDING, ADJUSTABLE SPEED,STOP-REVERSE-FORWARD FUNCTION

NO.OF CUT BLADE 2
SAWDUST MEASUREMENT <4MM
FEEDING OUTLET ROTATION ANGLE 360 DEGREE
WORKING EFFICIENCY 8-11 CUBIC METER
HYDRAULIC OIL TANK 26L

SPECIFICATION

MODEL WC-30
MAX DIA. OF FEEDING 200MM
POWER CHANGCHAI 390Q WITH CERTIFICATE(50HP,4 CYCLINDERS)
FLYWHEEL DIAMETER 600MM
FLYWHEEL TURNING SPEED 1025RPM
FEEDING SYSTEM

1. SINGLE HYDRAULIC FEEDING, ADJUSTABLE SPEED,STOP-REVERSE-FORWARD FUNCTION

2 DOUBLE HYDRAULIC FEEDING, ADJUSTABLE SPEED,STOP-REVERSE-FORWARD FUNCTION

NO.OF CUT BLADE 2
SAWDUST MEASUREMENT <4MM
FEEDING OUTLET ROTATION ANGLE 360 DEGREE
WORKING EFFICIENCY 8-9 CUBIC METER
HYDRAULIC OIL TANK 26L

SPECIFICATION

MODEL WC-22
MAX DIA. OF FEEDING 200MM
POWER CHANGCHAI L24M WITH CERTIFICATE(22HP,SINGLE CYCLINDER)
FLYWHEEL DIAMETER 600MM
FLYWHEEL TURNING SPEED 1025RPM
FEEDING SYSTEM

1. REDUCTION BOX FEEDING, ONLY FORWARD FUNCTION

2. SINGLE HYDRAULIC FEEDING, ADJUSTABLE SPEED,STOP-REVERSE-FORWARD FUNCTION

3. DOUBLE HYDRAULIC FEEDING, ADJUSTABLE SPEED,STOP-REVERSE-FORWARD FUNCTION

NO.OF CUT BLADE 2
SAWDUST MEASUREMENT <4MM
FEEDING OUTLET ROTATION ANGLE 360 DEGREE
WORKING EFFICIENCY 7-8 CUBIC METER
HYDRAULIC OIL TANK 16L

 SPECIFICATION

MODEL WC-18
MAX DIA. OF FEEDING 200MM
POWER CHANGCHAI 1115 WITH CERTIFICATE(18HP,SINGLE CYCLINDER)
FLYWHEEL DIAMETER 600MM
FLYWHEEL TURNING SPEED 1025RPM
FEEDING SYSTEM

1. REDUCTION BOX FEEDING, ONLY FORWARD FUNCTION

2. SINGLE HYDRAULIC FEEDING, ADJUSTABLE SPEED,STOP-REVERSE-FORWARD FUNCTION

3. DOUBLE HYDRAULIC FEEDING, ADJUSTABLE SPEED,STOP-REVERSE-FORWARD FUNCTION

NO.OF CUT BLADE 2
SAWDUST MEASUREMENT <4MM
FEEDING OUTLET ROTATION ANGLE 360 DEGREE
WORKING EFFICIENCY 7-8 CUBIC METER
HYDRAULIC OIL TANK 16L
